Abstract

Recent advances in deep learning have led to increased interest in solving high-efficiency end-to-end transmission problems using methods that employ the nonlinear property of neural networks. These methods, we call semantic coding, extract semantic features of the source signal across space and time, and design source-channel coding methods to transmit these features over wireless channels. Rapid progress has led to numerous research papers, but a consolidation of the discovered knowledge has not yet emerged. In this article, we gather ideas to categorize the expansive aspects on semantic coding as two paradigms, i.e., explicit and implicit semantic coding. We first focus on those two paradigms of semantic coding by identifying their common and different components in building semantic communication systems. We then focus on the applications of semantic coding to different transmission tasks. Our article highlights the improved quality, flexibility, and capability brought by semantic coded transmission. Finally, we point out future directions.

Method overview

Fig system

A system architecture of semantic coding, where explicit and implicit semantic coding paradigms specify each module as different functions.


Coded transmission system: classical vs semantic


Fig system

Comparison between different transmission systems.

Explicit coding demo


Fig system

Transmission RD results and visual comparisons of different coded transmission systems.

Implicit coding demo

Realistic 3D scenes can be transmitted over wireless channels using our ISC/HSC with high-fidelity details.


Bandwidth = 750KHz, Channel SNR =﹣5dB


Bandwidth = 3MHz, Channel SNR =﹣5dB



Bandwidth = 750KHz, Channel SNR = 0dB


Bandwidth = 3MHz, Channel SNR = 0dB



Bandwidth = 750KHz, Channel SNR = 10dB


Bandwidth = 3MHz, Channel SNR = 10dB



Bandwidth = 750KHz, Channel SNR = 20dB


Bandwidth = 3MHz, Channel SNR = 20dB
